First thing you should do is to update the firm-ware .
Function 1 - Conventional DSL modem works with BSNL BB ( Giving full speeds) .
Function 2 - 300Mbps 5DBi two antenna's not detachable but movable wifi router better than TP Link - MR 3220 or Old Teracom Modem provided by BSNL which I have . Antenna's in these router seem's to work very fine, Just move the antenna to the direction where signal is less and it will boost signal in that area.
Function 3 - 3G/EVDO Datacard support ( Supports ZTE AC 2766 and Sierra 595U ) ( Not supports D-Link DWP 157 , ZOOK 3.85GS) - Tested by me .
For EVDO DATACARDS connection isn't automatic , Go to 192.168.1.1 then in link type use 3g as primary then in secondary setup use country as other then ISP as other then APN blank then Username and password as your mobile no. and dial no as #777.
For 3G DATACARDS automatic connection works but in case it doesn't work , Go to 192.168.1.1 then in link type 3G as primary then in seconadary setup use Country as India then ISP from drop down and its done .
Function 4 - Share HDD / USB Sharing available ( I connected 1TB HDD and it working fine wirelessly - speed varies from 3MBPS-4.5MBPS). For sharing HDD/Pendrive via mobile use ES file explorer app ( In app go to lan then set IP as 192.168.1.1 and username/password as samba ). You could share multiple HDD's and Pendrive via it using a good usb hub but only condition is that 3G or EVDO Datacard should be disconnected if you are availing sharing service.
Process for newbie :
Step 1 A : Go to 192.168.1.1 from browser then ADVANCED then ADVANCED SETUP then storage services then check enable samba .
Step 1 B : Go to My Computer ( In windows 7 ) or This PC ( in windows 8/8.1) then In address bar type exactly \\192.168.1.1 then if asked for password and user name enter samba as password and username then you are done .
For Mobile : Go to ES file manager then Settings/options then slide down till you find Networks and In networks you will find LAN , In Lan press Plus symbol button then enter SERVER as 192.168.1.1 and username and password as samba then click OK .( Cheers !)
Function 5 - Print server , Works fine but not very reliable and also Datacard should be disconnected in order to avail print server facility . In my case print server was working with mine HP 1050 J5410 printer but after few hours it stopped working , But that wasn't the primary purpose for me to purchase these item so I let it go .
Process for Newbies to add your printer wirelessly :
Step 1 A : Go to 192.168.1.1 from your browser then username and password as admin then ADVANCED then ADVANCED SETUP then Print server then Check the box of enable print server then put your printer name or anything you wish in printer name and model no and save it .
Step 1 B: Open control panel then go to devices and printers
Step 2 : Below menu-bar their will be option to Add a printer just click that .
Step 3 : If your are in windows 7 , select option 2 that is mine printer is wireless then it would search your printer . If you are in windows 8.1 /8 then you willn't be asked anything .
Step 4 : Your printer will be visible ( Remember the Printer name which you gave earlier ) then just do next - next (If it ask for driver just check the box that add drivers automatically or just insert the driver DISC of printer and just browse for it )
Step 5 : It will print TEST page and you are done ( Cheers , if you reached till here).
And many more features available which will take a lot of time so Bye Bye for now !
| Brand | Tenda |
|---|---|
| Manufacturer | Tenda, Shenzhen Tenda Technology Co., Ltd. |
| Model | D303 |
| Model Name | TE-D303 |
| Model Year | 2015 |
| Product Dimensions | 17.2 x 3.4 x 11.1 cm; 132 Grams |
| Batteries | 1 Lithium Ion batteries required. |
| Item model number | D303 |
| Operating System | Windows |
| Compatible Devices | Compatible printer with Tenda D301 : Canon- IP3300, MF3010, MG2570, MF4412, E400, MP287, Epson - C45, L210, HP laserJet 1022, HP laserJet 1008, HP laserJet 1010, HP Deskjet 5740, HP Deskjet D2660, Lexmark- P6210, Samsung-SCX-3201G, SCX-4650, SCX-4521, Xerrox- 3117, Workcentre5019, RICOH- SP111 Note:- these printer are tested, more printer can work with router's print server |
| Special Features | USB Port |
| Mounting Hardware | D303, Power Adapter, Quick install guide, Ethernet Cable, ADSL splitter and 2 Telephone lines. |
| Colour Screen | No |
| Voltage | 9 Volts |
| Batteries Included | No |
| Batteries Required | No |
| Data Transfer Rate | 750 |
| Wireless Type | 802.11n, 802.11b, 802.11g |
| GSM frequencies | 2.4 GHz |
| Number of Ports | 4 |
| Total Usb Ports | 1 |
| Communication Interface | Wireless N |
| Connector Type | RJ-11 |
| Has Auto Focus | No |
| Includes Rechargable Battery | No |
| Programmable Buttons | No |
| Manufacturer | Tenda |
| Imported By | Fotune Marketing Pvt. Ltd. |
| Item Weight | 132 g |
